569-2647 PINION-DIFFERENTIAL BEVEL is a precision-engineered low alloy steel gear designed for Caterpillar heavy-duty differential systems. Featuring 16 straight bevel teeth, it works with the mating differential gears to transfer drivetrain power efficiently from the drive shaft toward the axle shafts. With its robust construction and precise gear profile, the part is suitable for demanding mining and heavy earthmoving applications on CAT 793-series haul trucks.
| Item | Specification |
|---|---|
| Product Name | PINION-DIFFERENTIAL BEVEL |
| Part Number | 569-2647 |
| Brand | Caterpillar |
| Machine Model | CAT 793D / 793C / 793F |
| Weight | 7.075 KG |
| Material | Low Alloy Steel |
| Condition | Brand New – Genuine |
| Warranty | 6 Months |
| Packaging | Standard Export Carton |
| Availability | Generally in stock |
| Origin | China |
Caterpillar identifies 569-2647 as a bevel pinion used in differential systems to transmit power from the drive shaft to the axle shafts. The official specifications identify the gear as steel/low alloy steel with 16 teeth.
The 569-2647 PINION-DIFFERENTIAL BEVEL is listed for several Caterpillar heavy-duty off-highway truck configurations, including:
Caterpillar’s compatibility list also includes 789B, 789C, 789D, 789G and other 793-series configurations. Customers should confirm the machine serial number and drivetrain configuration before ordering.
The 569-2647 PINION-DIFF is professionally packed for international transportation. Depending on order quantity and shipping requirements, reinforced wooden cases or heavy-duty export cartons can be arranged. Internal fixation and moisture-proof protection help keep the gear secure during handling and transportation.
YLCM provides flexible international logistics solutions according to destination and order requirements:
We can also coordinate consolidated shipments for customers purchasing multiple Caterpillar drivetrain components.
Q1: What is 569-2647?
A: 569-2647 is a Caterpillar Pinion-Differential Bevel used in differential systems to transmit power from the drive shaft to the axle shafts.
Q2: How many teeth does 569-2647 have?
A: The pinion has 16 straight bevel gear teeth.
Q3: What material is 569-2647 made from?
A: Caterpillar specifies low alloy steel for the part.
Q4: What are the dimensions of 569-2647?
A: The official specifications list an outside diameter of 215.72 mm, inside diameter of 93.218 mm and height of 61.768 mm.
Q5: Which Caterpillar machines use 569-2647?
A: The part is listed for CAT 793C, 793D and 793F, with additional compatibility across several 789 and 793-series trucks.
Q6: Is 569-2647 a complete differential assembly?
A: No. It is an individual bevel pinion component used within the differential system.
Q7: Can YLCM help confirm the correct part?
A: Yes. Send us the machine model, serial number and existing part number. Our technical team can help verify compatibility before quotation.
Looking for 569-2647 PINION-DIFF for CAT 793D, 793C or 793F?
Send us your required quantity, machine model and serial number. YLCM PARTS can provide product availability, quotation and international shipping options for your order.
