563-8599 SEAL GP-DUO for CAT 785/789/795F XQ

Features & Benefits

• Duo-Cone Seal Design: 563-8599 uses a metal-to-metal sealing interface designed to protect final-drive components from external particle intrusion.
• Reliable Oil Sealing: The Duo-Cone design helps maintain an oil-tight seal during continuous rotation and demanding operating conditions.
• Contamination Protection: Helps prevent dust, dirt and other abrasive particles from entering the final-drive system and damaging internal components.
• Heavy-Duty Construction: Designed for high-load off-highway applications where final-drive components experience significant mechanical stress.
• Supports Misalignment: Cat states that Final Drive Duo-Cone Seals maintain an oil-tight seal during rotation even where misalignment may occur.
• Toric Element Support: Rubber toric elements help position the metal sealing rings and maintain controlled sealing pressure during operation.
• Replacement Solution: Suitable for replacing worn or leaking final-drive seals during scheduled maintenance or drivetrain overhaul.

Compatible Machine

The 563-8599 Duo Seal Group is officially listed for a wide range of Caterpillar equipment, including:

• CAT 785
• CAT 789
• CAT 795F XQ
• CAT 785G
• CAT 789G
• CAT 789C
• CAT 789D
• CAT 785C
• CAT 785D
• CAT 793D
• CAT 793F
• CAT 797F
• CAT 795F AC
• CAT 794 AC

Caterpillar’s official parts catalog lists additional truck and off-highway truck configurations. Because final-drive configurations can vary, machine serial number verification is recommended before ordering.

Applications

The 563-8599 Duo Seal Group is used in the final-drive sealing system of heavy Caterpillar off-highway and mining trucks. It helps retain lubricant while protecting internal drivetrain components from abrasive contaminants.

Typical applications include:

• Mining
• Quarry
• Construction
• Heavy Earthmoving
• Large Infrastructure Projects

It is especially suited to heavy-duty haulage environments where dust, mud, high loads and long operating cycles can place significant demands on final-drive components.

Why Choose YLCM?

• 20+ Years Experience – Professional experience in construction and mining machinery parts.
• Large Warehouse – Extensive inventory covering Caterpillar, Komatsu and other major brands.
• Fast Delivery – Efficient order processing and worldwide logistics support.
• Genuine & OEM Parts – Genuine, OEM and high-quality replacement parts available.
• Export to 60+ Countries – Supporting customers across global construction and mining markets.
• Professional Technical Support – Assistance with part number verification, machine compatibility and final-drive component selection.

Packaging

YLCM provides secure export packaging for precision sealing components. Individual seals are protected against dust, moisture, contamination and impact, while reinforced packaging can be arranged for larger orders.

The standard product packaging specification is Standard Export Carton.

Shipping

YLCM supports international transportation according to destination, order quantity and delivery requirements:

• Sea Freight
• Railway Transportation
• Land Transportation
• Multimodal Logistics

Professional packing and secure handling help protect the sealing surfaces and rubber components throughout transportation.

Request a Quote

Looking for 563-8599 Duo Seal Group for a CAT 785, 789 or 795F XQ?

Send us your part number, machine model and serial number if available. YLCM can help verify compatibility and provide price, availability, lead time, packaging and shipping options.
