222-7251 Ring is a Caterpillar hardened steel component used with the speed sensor in the wheel and final drive group. Featuring 57 internal spline teeth and 48 external sensor teeth, it supports reliable rotational speed detection and final-drive operation on CAT 793D, 793F and 793F CMD mining trucks.
| Item | Specification |
|---|---|
| Product Name | Ring |
| Part Number | 222-7251 |
| Brand | Caterpillar |
| Machine Model | CAT 793D / 793F / 793F CMD / 793F OEM / 793F XQ |
| Application | Wheel & Final Drive Group |
| Part Type | Speed Sensor Ring |
| Internal Spline Teeth | 57 |
| External Teeth | 48 |
| Function | Speed Sensor Signal Generation |
| Material | Hardened Steel |
| Weight | 5 kg |
| Condition | Brand New – Genuine |
| Warranty | 6 Months |
| Packaging | Standard Export Carton |
| Availability | Generally in stock |
| Origin | China |
The 222-7251 Ring is listed by Caterpillar for:
Caterpillar also lists the part for the 793 and 793D/793F off-highway truck configurations. Machine serial number and wheel/final-drive configuration should be verified before ordering.
The 222-7251 Ring is installed in the wheel and final drive system of Caterpillar large mining trucks. It works with the speed sensor to provide rotational speed information while supporting proper operation of the final-drive assembly.
Typical applications include:
It is suitable for heavy haulage equipment operating under high loads, long working cycles and demanding off-road conditions.
YLCM provides secure export packaging for precision drivetrain components. The ring is protected against dust, moisture, impact and contamination during transportation.
The standard product packaging specification is Standard Export Carton. Reinforced wooden packaging can be arranged for larger or consolidated orders.
YLCM supports international transportation according to destination, order quantity and delivery requirements:
Professional packing and secure handling help protect the machined spline and sensor surfaces during international transportation.
Looking for 222-7251 Ring for a CAT 793D, 793F or 793F CMD?
Send us your part number, machine model and serial number if available. YLCM can help verify compatibility and provide price, availability, lead time, packaging and shipping options.
